- The instrument is equipped with a 10.1-inch large color touch screen (1024*600), designed with an easy-to-use graphical user interface.
- The main unit independently performs photometric measurement, quantitative analysis, spectrum scanning, kinetics, DNA/protein testing, and multi-wavelength testing.
- When controlled via PC software, it provides richer extension applications. The software adheres to GLP/GMP laboratory standards and includes comprehensive user management, log recording, data storage traceability, and report output functions.
- It boasts powerful storage capabilities, able to save various types of data and spectra, equipped with a standard USB interface for direct data exportation for editing, measurement, and storage. The instrument also features a power-off data retention function.
- The unique design provides excellent optical performance, utilizing a holographic grating monochromator and a digital photodiode
PRODUCT PARAMETERS
Optical System-Single Beam
Light Source-Tungsten Lamp(Japan HYBEC) | Deuterium Lamp (Milaras)
Spectral Bandwidth-1.0nm
Wavelength Range-190～1100nm
Wavelength Accuracy-±0.1nm (at 656.1nm), ±0.3nm full range
Scanning Speed-High | Medium | Slow
Wavelength Repeatability-≤0.1nm
Photometric Range–0.3～3A,0～9999C(0～9999F)
Photometric Accuracy-±0.0015A(0～0.5A)±0.002A(0.5A～1A)
Photometric Repeatability±0.001A(0～0.5A)±0.0015A(0.5A～1A)
Stability≤0.001 A/h / 500 nm(After 1 hour of preheating)
Stray Light≤0.03%T @ 220,360nm
Sample Compartment4 Cells, 10 mm
Display-10.1-inch large color touch screen(1024*600)
Output-USB Port Printer Port
Power Requirements-110/220V,50/60Hz,120W
Dimension[L×W×H]-570*440*210mm
Weight-20kg
